- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light ON
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night24/7 Color Imaging
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
- Signal SystemPAL/NTSC
- Slow ShutterMax. 16 times
- Light AlarmSolid Light Alarm (White Light)
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129°
3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100°
6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°
- Lens MountM12
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 40 m
- Smart Supplement LightYes
- Image
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Image SettingsBrightness, Contrast, Mirror, Sharpness, Anti-Banding, AGC
- Frame Rate
TVI: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC
- Day/Night ModeColor
- Wide Dynamic Range (WDR)≥130 dB
- Image EnhancementWDR, BLC, HLC, Global, HLS
- Privacy Mask4 programmable privacy masks
- Noise Reduction3D DNR/2D DNR
- White BalanceAuto
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- Event
- Motion Detection4 programmable motion areas
- General
- MaterialMetal
- Dimension194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
- WeightApprox. 515 g (1.14 lb.)
- Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power
12 VDC ± 25%, Max. 4.6 W
*You are recommended to use one power adapter to supply the power for one camera.
- Approval
- ProtectionIP68
