- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
- Day & NightColor
- Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type3.6 mm, 6 mm fixed lens
- Focal Length & FOV
3.6 mm, horizontal FOV: 83.0°, vertical FOV: 44.4°, diagonal FOV: 98.0°
6 mm, horizontal FOV: 51.0°, vertical FOV: 28.5°, diagonal FOV: 58.7°
- Lens MountM16
- Illuminator
- Supplement Light RangeUp to 40 m
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, Mirror, Smart Light, Defective Pixel Correction
- Frame Rate
TVI: 1080p@30fps, 1080p@25fps
AHD: 1080p@30fps, 1080p@30fps
CVI: 1080p@30fps, 1080p@25fps
CVBS: PAL/NTSC
- Wide Dynamic Range (WDR)≥130 dB
- Image EnhancementBLC, HLC
- White BalanceATW/MANUAL
- White LightAUTO/OFF
- AGCSupport
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- Material
Front Cover: Metal
Main Body: Plastic
- Dimension77.1 mm × 82.6 mm × 208.9 mm (3.04" × 3.25" × 8.22")
- WeightApprox. 441 g ( 0.97 lb.)
- Operating Condition-40° C to 60° C (-40° F to 140° F), Humidity 90% or less (no condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply
12 VDC ± 25%
*You are recommended to use one power adapter to supply the power for one camera.
- Consumption
Max. 8.5 W
- Approval
- ProtectionIP67
