- Camera
- Image Sensor5.0 megapixel progressive scan CMOS
- Max. Resolution2560 (H) × 1944 (V)
- Min. IlluminationColor: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens TypeFixed Lens
- Focal Length & FOV85.5° (2.8 mm), 80.1° (3.6 mm)
- Lens MountM12
- Image
- Image SettingsBrightness, Contrast, Sharpness, Saturation, DNR, Mirror
- Frame RatePAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fp
- Day/Night ModeAuto/Color/BW (Black and White)
- Image EnhancementBLC
- White BalanceAuto/Manual
- White LightAUTO/OFF
- AGCYes
- Supplement Detection(PIR)
- PIR RangeAngle: 110°, Range:11 m
- Interface
- Video OutputTVI only
- AlarmYes
- General
- MaterialFront cover: Metal,Main body: Plastic
- Dimension88.6 mm × 81.3 mm × 224.7 mm (3.49" × 3.20" × 8.85" )
- WeightApprox. 430 g (0.95 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- LanguageEnglish
- Power Supply12 VDC ±25%
- ConsumptionMax. 4 W
- IR RangeUp to 20 m
- Approval
- Protection1P67
